Flexible PV Solar Panels
>
|
| Place of Origin | China |
| Brand Name | MITSCN |
| Certification | ISO |
RS91-525_550MBG (210-132 bifacial module with dual glass)
Suitable for ground power plants and distributed projects
Advanced module technology delivers superior module efficiency
·Gallium-doped Wafer·Non destructive cutting ·MBB half-cut
Excellent power generation performance
·Excellent IAM and Weak light response ·Low temperature ratings ·0.55% linear Power decline
High module quality ensures long-term reliability
·Strict selected material ·Advanced technology ·Leading standard
Ultra-hydrophilic self-cleaning coating techniques
| RS91-525MBG-E1 |
RS91-530MBG-E1 | RS91-535MBG-E1 | RS91-540MBG-E1 | RS91-545MBG-E1 | RS91-550MBG-E1 | |
| 525W |
530W | 535W | 540W | 545W | 550W | |
| 0~+5W |
0~+5W | 0~+5W | 0~+5W | 0~+5W | 0~+5W | |
| 20.10% |
20.30% | 20.50% | 20.70% | 20.90% | 21.00% | |
| 17.04A |
17.11A | 17.16A | 17.21A | 17.24A | 17.29A | |
| 30.80V |
31.00V | 31.20V | 31.40V | 31.60V | 31.80V | |
| 18.14A |
18.19A | 18.24A | 18.30A | 18.35A | 18.39A | |
| 37.10V |
37.30V | 37.50V | 37.90V | 37.90V | 38.10V | |
| Values at Standard Test Conditions STC(AM1.5, Irradiance 1000W/m², Cell Temperature 25°C) | ||||||
| Electrical Characteristics NOCT | RS91-525MBG-E1 | RS91-530MBG-E1 | RS91-535MBG-E1 | RS91-540MBG-E1 | RS91-545MBG-E1 | RS91-550MBG-E1 |
| 298W | 401W | 405W | 409W | 413W | 416W | |
| 13.88A | 13.93A | 13.97A | 14.02A | 14.08A | 14.10A | |
| 28.60V | 28.80V | 29.00V | 29.02V | 29.40V | 29.50V | |
| 14.62A | 14.66A | 14.70A | 14.75A | 14.79A | 14.82A | |
| 35.00V | 35.10V | 35.30V | 35.50V | 35.70V | 35.90V | |
| NOCT, lrradiance of 800W/m2, AM1.5, Ambient Temperature 20 °C, wind Speed 1m/s. | ||||||
| Electrical Characteristics with 21% RS91-525MBG-E1 RS91-530MBG-E1 RS91-535MBG-E1 RS91-540MBG-E1 RS91-545MBG-E1 RS91-550MBG-E1 |
||||||
| Maximum Power (Pmax) | 562W | 567W | 573W | 578W | 583W | 598W |
| Maximum Power Current (lmp) | 18.23A | 18.31A | 18.36A | 18.41A | 18.45A | 18.50A |
| Maximum Power Voltage (Vmp) | 30.80V | 31.00V | 31.20V | 31.40V | 31.60V | 31.80V |
| Short Circuit Current (lsc) | 19.41A | 19.46A | 19.52A | 15.58A | 19.63A | 19.68A |
| Open Circuit Voltage (Voc) | 37.10V | 37.30V | 37.50V | 37.70V | 37.90V | 35.90V |
