48VDC Pure Sine Wave Inverter 6000W 10400W RS485 Monitoring
Product Summary
Pure Sine wave High Frequency solar Inverter(450V) Features Pure sine wave output Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc). MAX PV Array Open Circuit Voltage: 450V Can provide the power to the load without battery Combining solar system, AC utility, and battery power ...
Product Custom Attributes
48VDC Pure Sine Wave Inverter
,48V Pure Sine Wave Inverter 6000W
,10400W Pure Sine Wave Inverter
Basic Properties
Trading Properties
Product Description
Pure Sine wave High Frequency solar Inverter(450V)
Features
-
Pure sine wave output
-
Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
-
MAX PV Array Open Circuit Voltage: 450V
-
Can provide the power to the load without battery
-
Combining solar system, AC utility, and battery power source to supply
continuous power
-
Overload, short circuit and Deep discharge protection
-
Cold start function
-
Support USB, RS485 monitoring function
-
WIFI remote monitoring (optional)
-
Compatible to generator
| Model | PH18-3024 PRO | PH18-5248 PRO |
| Nominal Battery System Voltage | 24VDC | 48VDC |
| INVERTER OUTPUT | ||
| Rated Power | 3000VA / 3000W | 5200VA / 5200W |
| Surge Power | 6000W | 10400W |
| Waveform | Pure sine wave | |
| AC Voltage Regulation (Batt.Mode) | 230VAC±5%(Setting) | |
| Inverter Efficiency(Peak) | 90%~93% | |
| Transfer Time | 10ms (UPS / VDE4105) 20ms (APL) | |
| AC INPUT | ||
| Voltage | 230VAC±5% | |
| Selectable Voltage Range | 170~280VAC(UPS) / 90~280VAC(APL) | |
| Frequency Range | 50Hz/60Hz(Auto sensing) | |
| BATTERY | ||
| Normal voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27.4VDC | 54.8VDC |
| Overcharge Protection | 30VDC | 60VDC |
| SOLAR CHARGER & AC CHARGER | ||
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum PV Array Power | 5000W | |
| PV Array MPPT Voltage Range | 150~430 VDC | |
| Maximum Solar Charge Current | 80A | |
| Maximum AC Charge Current | 60A | |
| Maximum Charge Current | 80A | |
| MECHANICAL SPECIFICATIONS | ||
| Machine Dimensions (W*H*D)(mm) | 289*414*124.5 | 330*488*119 |
| Package Dimensions (W*H*D)(mm) | 393*488*251 | 396*638*241 |
| Net Weight(kg) | 8 | 14 |
| Gross Weight(kg) | 9.5 | 16.4 |
| OTHER | ||
| Humidity | 5% to 95% Relative humidity (Non-condensing) | |
| Operating Temperature | -10℃ ~50℃ | |
| Storage Temperature | -15℃ ~60℃ | |
