555W 560W N Type Solar Modules 570W Flexible Mono Facial Module

RS6-555-575N N-type (182-144 mono-facial module)

Suitable for ground power plants and distributed projects

Advanced module technology delivers superior module efficiency
·Gallium-doped Wafer·Non destructive cutting ·MBB half-cut

Excellent power generation performance

·Excellent IAM and Weak light response ·Low temperature ratings ·0.40% linear Power decline

High module quality ensures long-term reliability

·Strict selected material ·Advanced technology ·Leading standard

Ultra-hydrophilic self-cleaning coating techniques

Electrical Characteristics STC	RS6-555N-E3	RS6-560N-E3	RS6-565N-E3	RS6-570N-E3	RS6-575N-E3
Maximum Power (Pmax)	555W	560W	565W	570W	575W
Power Tolerance	0~+5W	0~+5W	0~+5W	0~+5W	0~+5W
	21.48%	21.68%	21.87%	22.07%	22.26%
Maximum Power Current (Imp)	13.16A	13.21A	13.27A	13.32A	13.38A
Maximum Power Voltage (Vmp)	42.20V	42.40V	42.60V	42.80V	43.00V
Short Circuit Current (Isc)	13.93A	13.99A	14.05A	14.11A	14.17A
Open Circuit Voltage (Voc)	50.40V	50.60V	50.80V	51.00V	51.20V
Values at Standard Test Conditions STC(AM1.5, Irradiance 1000W/m2, Cell Temperature 25°C)
Electerical Characteristics NOCT	RS6-555N-E3	RS6-560N-E3	RS6-565N-E3	RS6-570N-E3	RS6-575N-E3
Maximum Power (Pmax)	421W	424W	428W	432W	436W
Maximum Power Current (Imp)	10.61A	10.65A	10.70A	10.74A	10.79A
Maximum Power Voltage (Vmp)	39.60V	39.80V	40.00V	40.20V	40.40V
Short Circuit Current (Isc)	11.23A	11.28A	11.33A	11.38A	11.42A
Open Circuit Voltage (Voc)	48.20V	48.40V	48.60V	48.70V	48.90V
